Tento post logicky navazuje i na diskuzi tu, zde mi však přijde logičtější..
Objevil jsem v souvislosti s D-class zesákama zajímavej post na tomto fóru Dovolím si ho citovat
Aussie Mark napsal:Which amps use the Bang & Olufsen Icepower power modules
From one of my FB friends who works for B&O, here's the definitive answer on which bass amps use these modules ...
50ASX2 is used bridged for what we call 180w at 4ohms in the following amps: GK MB200 and any 200 watt GK combo, Fender Rumble 200 and any of the 100w/200w combos, Traynor SB200 and 200 watt Traynor combos
125ASX2 is used bridged for what we rate as 450w at 4ohm in the following amps: GK MB500, MB500 fusion and any GK 500 watt combo, Aguilar Tonehammer 350, GB Shuttle 6 and Streamliner 600, Tecamp Puma 500 (1u), Eden WTX500, Fender Rumble 500 (the new rumbles are actually quite nice), any fender 350 w combo, Traynor SB500
The 250ASX2 is used bridged for what we would rate around 800w at 4ohm in the following amps: GK MB800 and MB800 Fusion, Aguilar Tonehammer 500, GB Shuttle 9 and Streamliner 900, Tecamp Puma 900, Demeter 800w class D amps
Jestli je to pravda, dají se technické informace (bez peak poweru a podobných kulišáren) k jednotlivým koncákům snadno dohledat, např. já mám traynora SB500, a pro daný koncák platí tedy:
Nominal power, 1% THD+N, SE-mode, 4Ω, 1kHz - 2 x 125W
Nominal power, 1% THD+N, BTL mode, 4Ω, 1kHz - 450W
Maximal power, 10% THD+N, BTL-mode, 4Ω, 1kHz - 500W
Bandwidth, 8Ω, -3dB point - 100kHz
Frequency response 20Hz-20kHz, 2Ω-8Ω load range - +/-0.5dB
Damping factor, 8Ω, 100Hz - >500
THD+N 1kHz, 1W -0.003%
Dynamic Range, A-weighted - 121dB
plný datasheet tu
